Quality & Affordability in Synergy
99.99% Copper Winding Motor
Features
- 5 Spindle Speed for better matching of speed to application
- 16mm drilling cpacity for all large drilling applications
- Locking depth stop for accurate blind hole drilling
- Fully Adjustable Table with Angle Indicator
- Cast Iron Base for added stability
Specifications
Drilling Capacity : 3-16mm
Spindle Travel : 60mm
Spindle Taper : B16
Speed of Spindle : 5
Rotary Radius of Table : 127mm
Table Size : 190x190mm
Base Size : 340x205mm
Max Distance Between Spindle Tip and Column : 420mm
Max Distance Between Spindle Tip and Base : 600mm
Dia of Column : Ø58mm
Motor Power : 375W(1/2HP)
Total Overall Dimension : 580x330x860mm
6 MONTHS WARRANTY
