FEATURES:
- The design allows straight edges, contours, and cutouts to be beveled with ease
- Works with steel, stainless steel, aluminum, copper, plastic and other materials
- The precision dial scale allows precise adjustment of the chamfer height
- The precision dial scale allows precise adjustment of the chamfer height
- Variable electronic speed control allows stable cutting speed, no matter the load, for precision results with various materials
- Optional tool holders with different bevel angles available
SPECIFICATIONS:
Model | EB12 |
---|
Power Input | 1800W |
---|
Voltage | 220V~60Hz |
---|
No Load Min-1 | 2300 - 6500 |
---|
Speed Wheel Settings | 1/ 2/ 3/ 4/ 5/ 6: 2300/ 2600/ 3700/ 4800/ 5800/ 6500 |
---|
Std. Bevel Angle | 45 Deg. |
---|
Max. Chamfer Height | 45 Deg. : 10.6 mm |
---|
Mini. Dia. For Inside Bevels | 30mm |
---|
Soft Start & Overload Protection | With |
---|
Dimensions(LxWxH) | 485mm x 192mm x 150mm |
---|
Net Weight | 6.35kg(14Lbs) |
---|
Standard Accessories: 45 Deg. Tool Holder Set, Square Carbide Inserts 6pcs. Torx Wrench T15, HEx Wrench m6, Hook Spanner Wrench, Spindle Lock Bar
