FEATURES: Stainless steel hex head cap screws are manufactured with a six-sided trimmed hex head that maintains a washer head on the bearing face.
These types of hex head bolt fasteners are often utilized in OEM applications that require precise tolerances.
The hex head bolt’s stainless steel construction provides numerous beneficial qualities that cannot be matched by materials that offer less protection.
Stainless hex cap screws also provide increased strength at higher temperatures.
SPECIFICATIONS:
- Increased bearing surface area
- Improved clamping pressure
- Flat washer facing under the bolt head
- Fine and coarse threads
STEEL : 304 Stainless Steel
BOLT : Hexagonal Cap Screw
PITCH : 24T;20T;18T;16T;14T;13T
MINIMUN ORDER QTY : 4Pcs
Size in Inches
| Size | 3/16 | 1/4 | 5/16 | 3/8 | 7/16 | 1/2 |
| Length /Pitch | 24T | 20T | 18T | 16T | 14T | 13T |
| 3/8 | 2.32 | 2.42 | | | | |
| 1/2 | 2.44 | 2.44 | 4.42 | 5.52 | | |
| 5/8 | 2.66 | 2.76 | 4.63 | 6.07 | | |
| 3/4 | 2.87 | 2.94 | 4.97 | 7.07 | 13.95 | 18.90 |
| 1 | 3.31 | 3.42 | 5.74 | 8.28 | 14.46 | 19.87 |
| 1-1/4 | 3.15 | 4.08 | 6.62 | 9.50 | 15.96 | 20.98 |
| 1-1/2 | 3.97 | 4.50 | 7.51 | 11.04 | 17.11 | 23.18 |
| 1-3/4 | 5.52 | 5.62 | 8.62 | 12.14 | 18.77 | 23.74 |
| 2 | 5.52 | 5.62 | 9.05 | 13.80 | 24.29 | 27.60 |
| 2-1/4 | | 6.62 | 10.70 | 1.54 | 27.00 | 32.35 |
| 2-1/2 | 6.62 | 7.07 | 11.04 | 16.00 | 28.70 | 33.12 |
| 2-3/4 | | 7.94 | 12.86 | 17.66 | 32.40 | 35.33 |
| 3 | 7.94 | 7.94 | 14.02 | 18.77 | 33.12 | 37.54 |
| 3-1/2 | | 10.00 | 16.78 | 22.08 | 37.54 | 41.95 |
| 4 | 9.94 | 14.14 | 19.87 | 24.29 | 42.50 | 46.37 |
| 4/1/2 | 13.25 | 20.42 | 27.38 | 28.70 | 46.09 | 55.20 |
| 5 | | 22.08 | 27.94 | 32.02 | 49.68 | 64.03 |
| 5-1/2 | | 24.18 | 34.78 | 38.64 | 56.30 | 66.24 |
| 6 | | 26.28 | 41.78 | 40.80 | 62.93 | 72.86 |
| 6-1/2 | | | | 19.49 | | 97.15 |
| 7 | | | | 97.15 | | 103.78 |
| 7-1/2 | | | | 103.78 | | 110.40 |
| 8 | | | | 110.40 | | 117.24 |
| 8-1/2 | | | | 114.00 | | |
| 9 | | | | 117.02 | | 132.48 |
| 10 | | | | 132.48 | | 150.14 |
| 11 | | | | 154.56 | | 187.68 |
| 12 | | | | 176.64 | | 220.80 |
